8 Axis Pipe Tube Cutting Beveling Machine can cut round pipe , square tube , rectangular tube , h beam in one machine . It can cut and bevel in one time .Widely used forSteel Structure, Bridge Construction, Machinery Manufacturing, Metal Processing, Pipeline Engineering, Shipbuilding ect indus
CONTACT
8 Axis Pipe Tube Cutting Beveling Machine can cut round pipe , square tube , rectangular tube , h beam in one machine . It can cut and bevel in one time .Widely used for Steel Structure, Bridge Construction, Machinery Manufacturing, Metal Processing, Pipeline Engineering, Shipbuilding ect industry .
Software support :Solidworks , Autocad , Tekla .
Cutting method :Plasma +Flame
Cutting Head :TCP cutting bevel head
Details configuration :
Pipe Tube | Square tube width | Φ= 80～400mm |
Pipe diameter | Φ=60～630mm | |
Channel beam | Φ= 80～400mm | |
H beam | Φ= 80～400mm | |
Angle beam | Φ=80～400mm | |
I beam | Φ= 80～400mm | |
Material length | 12000mm | |
Material | Mainly used for thermal cutting of coherent lines as well as plate and ends of various piping systems. Applicable workpiece materials: mild steel (copper-nickel, stainless steel, aluminum, galvanized materials require plasma cutting) | |
Cutting method | Cutting method | Plasma |
Pipe Wall thickness | LGK-200HD plasma power , it can cut 1-20mm thickness | |
Machine precision
| Required workpiece ellipticity | ≤1% |
Cutting speed | 10～2000mm/min | |
Moving speed | 10～6000 mm/min | |
Cutting length accuracy | ±1.5mm | |
Cutting accuracy implementation standard | ISO9013-2002、ISO8206-1991 And JB/T10045.4-1999JB | |
Chuck | Pipe chuck | Manually operated mechanical 4-jaw self-centering chucks |
Square tube chuck | Manually operated mechanical 4-jaw self-centering chucks | |
Manual chuck tightening device | 2 set | |
Bracket | Quantity | 5 groups |
Weight | Load | 5000Kg |
Color | Machine color | Blue |
